Electric Geyser Horizontal (Outdoor Unit)

Rapid Cool Horizontal Electric Geysers (Outdoor Units) are designed for efficient and continuous hot water generation in residential, commercial, and industrial applications. Built with robust construction and high-quality materials, these geysers ensure long-lasting performance with minimal maintenance.

Engineered for outdoor installation, the unit features a durable mild steel or optional stainless steel body, advanced insulation, and precision temperature control systems. With easy operation and reliable safety features, Rapid Cool geysers deliver consistent hot water output while maintaining energy efficiency and operational safety.

Easy Maintenance

• High-quality body and shell construction with precision welding
• Durable electrical wiring and control panel ensure long service life
• Minimal maintenance required under normal operating conditions
• Simple installation with water and electrical connections
• Service support available across the country for quick assistance

Constructional Features

• Available in Horizontal design for space-efficient outdoor installation
• Tank body made from Mild Steel (MS) with optional Stainless Steel (SS)
• Equipped with immersion-type heating elements (Copper / SS / Incoloy)
• Chrome-plated heating elements for enhanced durability
• Integrated electrical control panel for automatic temperature regulation
• High-standard internal wiring for safe operation

Technical Specifications

• Shell Type: Horizontal
• Material: Mild Steel / Stainless Steel (optional)
• Pressure Testing: 250–350 PSIG (as per requirement)
• Insulation:
  – 50 / 100 mm resin-bonded fiberglass wool
  – Density: 24–32 kg/m³
  – Cladded with 0.8 mm aluminum sheet
• Heater Specifications:
  – Voltage: 240V ±10%
  – Frequency: 50 Hz
  – Power Supply: 3 Phase AC
  – Flange Type Heating Element
  – ‘U’ Tube: Copper / SS / Incoloy
• Design Note:
  Heating elements are installed for easy removal without disturbing other components

Controls

• Digital temperature controller for accurate and consistent heat management

Safety Features

• Float Switch
• Pressure Relief Valve
• Door Switch
• Safety Thermostat

Capacity Range

• 50 Liters to 4000 Liters
• Storage type construction for continuous hot water availability
