Features:-
| Specification | Unit | RS-AS-19 | RS-AS-25 | RS-AS-37 | RS-AS-37V | RS-AS-45 | RS-AS-45V |
| HP | 5 HP | 7 HP | 10 HP | 10 HP | 12 HP | 12 HP | |
| Heating Capacity | kW | 19 | 25 | 37 | 37 | 45 | 45 |
| COP | 4.2 | 4.15 | 4.2 | 4.2 | 4.16 | 4.18 | |
| Rated Hot Water Output | L/H | 540 | 710 | 1070 | 1070 | 1270 | 1270 |
| Rated Water Temp | °C | 55 | 55 | 55 | 55 | 55 | 55 |
| Max Water Temp | °C | 60 | 60 | 60 | 60 | 60 | 60 |
| Input Power | kW | 4.4 | 6 | 8.8 | 8.8 | 11.1 | 11.1 |
| Current | A | 8.4 | 11.4 | 16.7 | 16.7 | 20.1 | 20.1 |
| Power Supply | 380–415V / 50Hz / 3Ph | 380–415V / 50Hz / 3Ph | 380–415V / 50Hz / 3Ph | 380–415V / 50Hz / 3Ph | 380–415V / 50Hz / 3Ph | 380–415V / 50Hz / 3Ph | |
| Compressor | Scroll (Emerson Copeland / Panasonic) | Scroll (Emerson Copeland / Panasonic) | Scroll (Emerson Copeland / Panasonic) | Scroll (Emerson Copeland / Panasonic) | Scroll (Emerson Copeland / Panasonic) | Scroll (Emerson Copeland / Panasonic) | |
| Number of Compressor | 1 | 1 | 1 | 1 | 1 | 1 | |
| Heat Exchanger (Condenser) | Tube-in-Shell Heat Exchanger / Brazed Plate Heat Exchanger | Tube-in-Shell Heat Exchanger / Brazed Plate Heat Exchanger | Tube-in-Shell Heat Exchanger / Brazed Plate Heat Exchanger | Tube-in-Shell Heat Exchanger / Brazed Plate Heat Exchanger | Tube-in-Shell Heat Exchanger / Brazed Plate Heat Exchanger | Tube-in-Shell Heat Exchanger / Brazed Plate Heat Exchanger | |
| Evaporator | Blue Finned Evaporator Coil | Blue Finned Evaporator Coil | Blue Finned Evaporator Coil | Blue Finned Evaporator Coil | Blue Finned Evaporator Coil | Blue Finned Evaporator Coil | |
| Throttling Device | Thermostatic Expansion Valve | Thermostatic Expansion Valve | Thermostatic Expansion Valve | Thermostatic Expansion Valve | Thermostatic Expansion Valve | Thermostatic Expansion Valve | |
| Water Flow | m³ | 3.2 | 4.3 | 6.3 | 6.3 | 7.5 | 7.5 |
| Fan Quantity | Piece | 1 | 1 | 1 | 1 | 1 | 1 |
| Refrigerant | R407C / R410A | R407C / R410A | R407C / R410A | R407C / R410A | R407C / R410A | R407C / R410A | |
| Noise at 1 Meter | dB(A) | ≤65 | ≤65 | ≤65 | ≤65 | ≤66 | ≤67 |
| Pipe Size | inch | 1/2 | 1/2 | 1/2 | 1/2 | 1/2 | 1/2 |
