| Specification | Unit | RS-SP-11 | RS-SP-14 | RS-SP-21 | RS-SP-27 | RS-SP-35 | RS-SP-45V | RS-SP-55V |
| HP | 2.5 | 3 | 5 HP | 6 HP | 8 HP | 10 HP | 12 HP | |
| Heating Capacity | kW | 11 | 14 | 21 | 27 | 35 | 45 | 55 |
| COP | 3.93 | 4 | 4.87 | 4.84 | 4.86 | 4.84 | 4.82 | |
| Max Output Water Temp | °C | 45 | 45 | 45 | 45 | 45 | 45 | 45 |
| Power Supply | 380–415V / 50Hz / 3Ph | 380–415V / 50Hz / 3Ph | 380–415V / 50Hz / 3Ph | 380–415V / 50Hz / 3Ph | 380–415V / 50Hz / 3Ph | 380–415V / 50Hz / 3Ph | 380–415V / 50Hz / 3Ph | |
| Input Power | kW | 2.8 | 3.5 | 4.4 | 5.28 | 7.3 | 9.4 | 10.95 |
| Current | A | 5 | 5.9 | 8.3 | 10 | 13.9 | 17.9 | 20.8 |
| Max Input Power | kW | 4.5 | 5.3 | 6.1 | 7.5 | 10 | 13.5 | 15.1 |
| Max Current | A | 8.2 | 10.3 | 11.6 | 14.4 | 19 | 25.6 | 28.7 |
| Evaporator | Blue Finned Evaporator Coil | Blue Finned Evaporator Coil | Blue Finned Evaporator Coil | Blue Finned Evaporator Coil | Blue Finned Evaporator Coil | Blue Finned Evaporator Coil | Blue Finned Evaporator Coil | |
| Throttling Valve | Thermostatic Expansion Valve | Thermostatic Expansion Valve | Thermostatic Expansion Valve | Thermostatic Expansion Valve | Thermostatic Expansion Valve | Thermostatic Expansion Valve | Thermostatic Expansion Valve | |
| Heat Exchanger (Condenser) | PVC Shell Titanium Condenser | PVC Shell Titanium Condenser | PVC Shell Titanium Condenser | PVC Shell Titanium Condenser | PVC Shell Titanium Condenser | PVC Shell Titanium Condenser | PVC Shell Titanium Condenser | |
| Refrigerant | R407C / R410A | R407C / R410A | R407C / R410A | R407C / R410A | R407C / R410A | R407C / R410A | R407C / R410A | |
| Compressor | Reciprocating | Reciprocating | Scroll (Emerson Copeland / Panasonic) | Scroll (Emerson Copeland / Panasonic) | Scroll (Emerson Copeland / Panasonic) | Scroll (Emerson Copeland / Panasonic) | Scroll (Emerson Copeland / Panasonic) | |
| Number of Compressor | 1 | 1 | 1 | 1 | 1 | 2 | 2 | |
| Fan Quantity | Piece | 1 | 1 | 1 | 1 | 1 | 2 | 2 |
| Fan Discharging | Horizontal | Horizontal | Horizontal | Horizontal | Vertical | Vertical | Vertical | |
| Water Flow | m³/H | 4.8 | 6 | 9 | 12.5 | 15 | 20 | 23 |
| Pipe Size | inch | 1-1/2 | 1-1/2 | 1-1/2 | 1-1/2 | 2 | 2 | 2 |
| Noise at 1 Meter | dB(A) | ≤53 | ≤55 | ≤56 | ≤58 | ≤61 | ≤61 | ≤66 |
| Dimension (L × W × H) | mm | 1250 × 660 × 725 | 1250 × 660 × 725 | 800 × 800 × 1025 | 800 × 800 × 1025 | 1100 × 1100 × 1295 | 1650 × 950 × 1625 | 1650 × 950 × 1625 |
| Weight | kg | 120 | 130 | 150 | 170 | 244 | 284 | 316 |
Features:-
| Specification | Unit | RS-SP-11 | RS-SP-14 | RS-SP-21 | RS-SP-27 | RS-SP-35 | RS-SP-45V | RS-SP-55V |
| HP | 2.5 | 3 | 5 HP | 6 HP | 8 HP | 10 HP | 12 HP | |
| Heating Capacity | kW | 11 | 14 | 21 | 27 | 35 | 45 | 55 |
| COP | 3.93 | 4 | 4.87 | 4.84 | 4.86 | 4.84 | 4.82 | |
| Max Output Water Temp | °C | 45 | 45 | 45 | 45 | 45 | 45 | 45 |
| Power Supply | 380–415V / 50Hz / 3Ph | 380–415V / 50Hz / 3Ph | 380–415V / 50Hz / 3Ph | 380–415V / 50Hz / 3Ph | 380–415V / 50Hz / 3Ph | 380–415V / 50Hz / 3Ph | 380–415V / 50Hz / 3Ph | |
| Input Power | kW | 2.8 | 3.5 | 4.4 | 5.28 | 7.3 | 9.4 | 10.95 |
| Current | A | 5 | 5.9 | 8.3 | 10 | 13.9 | 17.9 | 20.8 |
| Max Input Power | kW | 4.5 | 5.3 | 6.1 | 7.5 | 10 | 13.5 | 15.1 |
| Max Current | A | 8.2 | 10.3 | 11.6 | 14.4 | 19 | 25.6 | 28.7 |
| Evaporator | Blue Finned Evaporator Coil | Blue Finned Evaporator Coil | Blue Finned Evaporator Coil | Blue Finned Evaporator Coil | Blue Finned Evaporator Coil | Blue Finned Evaporator Coil | Blue Finned Evaporator Coil | |
| Throttling Valve | Thermostatic Expansion Valve | Thermostatic Expansion Valve | Thermostatic Expansion Valve | Thermostatic Expansion Valve | Thermostatic Expansion Valve | Thermostatic Expansion Valve | Thermostatic Expansion Valve | |
| Heat Exchanger (Condenser) | PVC Shell Titanium Condenser | PVC Shell Titanium Condenser | PVC Shell Titanium Condenser | PVC Shell Titanium Condenser | PVC Shell Titanium Condenser | PVC Shell Titanium Condenser | PVC Shell Titanium Condenser | |
| Refrigerant | R407C / R410A | R407C / R410A | R407C / R410A | R407C / R410A | R407C / R410A | R407C / R410A | R407C / R410A | |
| Compressor | Reciprocating | Reciprocating | Scroll (Emerson Copeland / Panasonic) | Scroll (Emerson Copeland / Panasonic) | Scroll (Emerson Copeland / Panasonic) | Scroll (Emerson Copeland / Panasonic) | Scroll (Emerson Copeland / Panasonic) | |
| Number of Compressor | 1 | 1 | 1 | 1 | 1 | 2 | 2 | |
| Fan Quantity | Piece | 1 | 1 | 1 | 1 | 1 | 2 | 2 |
| Fan Discharging | Horizontal | Horizontal | Horizontal | Horizontal | Vertical | Vertical | Vertical | |
| Water Flow | m³/H | 4.8 | 6 | 9 | 12.5 | 15 | 20 | 23 |
| Pipe Size | inch | 1-1/2 | 1-1/2 | 1-1/2 | 1-1/2 | 2 | 2 | 2 |
| Noise at 1 Meter | dB(A) | ≤53 | ≤55 | ≤56 | ≤58 | ≤61 | ≤61 | ≤66 |
| Dimension (L × W × H) | mm | 1250 × 660 × 725 | 1250 × 660 × 725 | 800 × 800 × 1025 | 800 × 800 × 1025 | 1100 × 1100 × 1295 | 1650 × 950 × 1625 | 1650 × 950 × 1625 |
| Weight | kg | 120 | 130 | 150 | 170 | 244 | 284 | 316 |
